Glue Dispensing Machine, semi-Automatic/manually Operated Dropper Machine, Pneumatic Dispensing Controller,Glue Pen, Foot Switch and Fixing Bracket

Semi-automatic glue dispensing machines are suitable for most yellow glue, quick-drying glue, epoxy resin, etc.SpecificationsMaterial: MetalGlue dispensing method: Manual/semi-automaticMinimum glue dripping amount: 0.01mlGlue dispensing time interval: 0.1-9.9sAutomatic timing (adjustable): 1-30sRepeat accuracy: ±0.5%Internal voltage: 12-24V DCInput air pressure: 2.5-7bar (35-100psi)Output air pressure: 0.1-5.5bar (1-78psi)Power supply: 110V-220V/50-60HZPower consumption: 20WProduct size: 23*15*6cm/9.05*5.9*2.36inPackaging size: 20*26*14cm/10*9*12.5inGross weight: 2.1kg/4.63 lbsPackage includes: 1* Dispensing machine host1* Manual switch1* Foot switch1* Air pipe1* Power cord1* Dispenser stand2* Liquid barrel6* Dispenser needles1* Instruction manualNotes:The input high pressure should not exceed 7 bar (100psi), and the maximum working pressure of the glue dropper should not exceed 5.5 bar (78psi). If the working air pressure is higher than 4 bar, please use an aluminum connector instead.If conditions permit, please store all materials at a constant temperature (5°) as instructed to ensure that the concentration does not change significantly during use.When the material concentration is too high (difficult to flow), it cannot drip. If you need to use it, please dilute it according to the manufacturer's instructions.In the automatic state, it is generally more appropriate to adjust the air pressure in the machine to 1-2.7bar (15-40psi). When working in the automatic state, the strength of the vacuum tube to draw back the air should be adjusted to an appropriate position.

• 【Widely used】Automatic glue dispensing machines are widely used in electronics, aviation, optics, chemicals, automobiles, medical, petroleum, packaging, jewelry, machinery and other industries
• 【Quick start】This product uses high-quality electronic valves, which can instantly start the diaphragm valve and improve work efficiency by more than 80%. The use of high-end all-copper coil can stabilize voltage changes and extend service life.
• 【Semi-automatic glue dispenser】It can be glued automatically by the machine and can be precisely controlled by a single-hole manual switch. If you want to your hands, you can set the switch to the automatic position to achieve a more efficient and higher-quality working method.
• 【High precision】The glue dispenser can accurately control the number of spray points and the spray point cycle. The minimum glue dripping amount is 0.01ML, and the glue spraying interval is 0.01~99.99S. It can accurately drip glue, and the repetition accuracy can reach about 0.5%.
